Model Number: LR2000 Series
Product Type: Desktop Regulator Terminal / Point-of-Use Regulator
Mounting Style: Table Mount / Bench Mount / Desktop Mount / Ceiling Mount
Inlet Pressure Options: 10 bar / 16 bar / 25 bar / 40 bar
Outlet Pressure Range: 0–25 bar
Body Materials: SUS316L, SS304 stainless steel
Wetted Materials: SUS316L, Hastelloy, PCTFE, PTFE
Operating Temperature: –40 °C to +74 °C (–40 °F to +165 °F)
Leak Rate: ≤ 2 × 10⁻⁸ atm·cc/sec (He)
Flow Coefficient (Cv): 0.15
